Cardlan access control card Reader RFID proximity reader Stationary RFID QR scanner smart ticketing machine

Item No.: RS232
Stationary RFID QR scanner smart ticketing machine tcp/ip smart terminal with NFC and Barcode scanner communication etc.
Description
Description

Stationary RFID QR scanner smart ticketing machine tcp/ip smart terminal with NFC and Barcode scanner communication etc. Can be used for electronic payment or card validation in following field:

Public transport IC card payment
Scenic spots/amusement park card payment
Employee shuttle bus card validation
Safety school bus IC card system


Name
Bus POS terminal
Operating system
Linux2.6.17.14
CPU
ARM9 core processor,240Mhz
Memory
32MBytes SDRAM,512MB NANDFlash main memory
Data capacity
2 million pcs of detailed data for console storage, unlimited data at GPRS storage
Blacklist
2 million pcs (download from PC with USB)
Working temperature
-25℃~65℃
Storage temperature
-40℃~85℃
Working humidity
0-90%(non-condensing)
Dimension
151x195x48mm
Housing material
Engineering plastics
Display
3.5 inch LCD display, 320x480
Indicator light
Red and green
Wifi
Support 802.11n/b/g standard,150Mbps,2.4Ghz
Scan Support type
Support 2D code include QR code, PDF417,Aztec code, Maxicode,MicroPDF417* etc.
Support 1D code include code 128, EAN-13,EAN-8.CODE39, UPC-A, UPC-E, Codabar, interleaved 2 of 5, ITF-6, ITF-14, ISBN, CODE 93, UCC/EAN-128, GS1 Databar, GS1 Composite Code, Matrix 2 of5, Code11, Industrial 25, Standard 25, Plessey, MSI-Plessey etc.
Reading distance
70mm~170mm
Printing module
Support external POS58printer
(need 5pinaviation plug turn DB9 cable)
Positioning way
GPS positioning
Power consumption
≤10 W
Wireless communication

2GPRS quad (850/900/1800/1900 MHz) ;2GCDMA(800Mhz);
4G(2G GSM(850/900/1800/1900 MHz)/
3GTD-SCDMA(1880-1920MHz/2010-2025MHz)/
WCDMA(2100MHz/1900MHz/850MHz)/
CDMA2000(1920-1935MHz/2110-2125MHz);
4G TDD-LTE(1900MHz/2300MHz/2600MHz)/
FDD-LTE(1800MHz/2600MHz)

Data collection function
WIFI/GPRS wireless collection and USB local collection
