1. Network with the GPS announcer, automatically show and broadcast the bus arrival information, reminding passengers to get off bus.
2. The LCD display can be divided into 3 sections respectively:
Zone 1: Display the name of the arriving station the next stop.
Zone 2: weather, time, speed, temperature, etc,as well as various tips
Zone 3: Video for advertisement content and all passing stop names
3. Tailored for bus, completely self-developed and self-built, remote advertising-releasing platform, which can remotely update the route number, advertising content, APKautomatic upgrade, network TV play, weather forecast broadcast or public emergency alert.
4. One of the motherboards adopts Android motherboard (independent research and development), which has high reliability, high security, fast booting speed and wideadaptability (-40°C to +80°C), which is very suitable for rail transit application.
|
Specification
|
Commonly recommended size |
29Inch |
|
Display Parameters
|
physical dimension |
801(H)×233(W)×47 mm(D) |
| Display demension |
705mm×198mm |
| Diagonal size |
29inch |
| Resolution |
1920(RGB)×540 |
| Brightness (typical value) |
500 cd/m² (Typ.) |
| Operating temperature |
0 ~ 50 °C |
| storage temperature |
-20 ~ 60 °C |
| life |
50000h |
Electrical parameters |
operating system |
Android |
| cpu |
A53, quad core, 1.7GHz |
| RAM |
1GB |
| store |
8GB |
| Ethernet port |
one line |
| bright adjustment |
Light perception/software adjustable |
| WIFI |
Optional |
| 4G-module |
Optional |
| USB interface |
one line |
| RS-485 |
Linkage with vehicle host |
| Audio |
Support dual 20W output |
| Power consumption (maximum) |
＜30W |
| Instantaneous electric burst interference |
±2KV |
| Electrostatic discharge |
Air ±8KV; contact ±6KV |
| Input voltage range |
DC9V～DC32V |
Mechanical |
Installation |
Two ears type / bow holder type |
| Weight |
6Kg(approx) |
|
Support video format |
H.264, MPEG4 |
|
Support picture format |
JPEG，PNG、BMP |
|
Video playback control |
Support |
|
In and out of station picture linkage |
Support |
|
Software customized UI interface |
Support |
| Special feature |
|
Customized Android motherboard, highly integrated, less wiring, stable and reliable
|
