1. Application
CL-0409C bus POS can support RFID card,with GPS positioning moduleand QR code scanner, support 4G,WIFI wireless communication etc.Can be used for electronic payment or card validation in following field：
l Public transport IC card payment
l Scenic spots/amusement park card payment
l Employee shuttle bus card validation
l Safety school bus IC card system
2. Functional features
l Support wireless communication,remote connect to server management software to realize real time time-revision,black-list downloading and data collection etc.
l Support data real time uploading or USB local data collection.
l Support live voice prompts, supports 15 kinds of voice prompts：such as "student card","employee card".
l Support consumption details and statistics query,according to card No.,time,operator No.,etc.
Parameter
|
Model:
|
CL1306 bus pos terminal
|
|
Dimension:
|
200*151*61.5mm
|
|
Material:
|
Engineering Plastics, Anti static electricity coating design, be protected from high-frequency interference
|
|
Display:
|
3.5 inch LCD display，320x240
|
|
Operating system:
|
Linux 2.6 system
|
|
CPU:
|
N32905 processor，ARM9 core @ 240MHZ
|
|
Memory:
|
32MBytes SDRAM，512MB NANDFlash
|
|
Data capacity:
|
259840 pcs of detailed data for console storage, unlimited data at GPRS storage
|
|
Card capacity:
|
91,880,000 pcs
|
|
Black list:
|
91,880,000 pcs (download thru PC with USB)
|
|
Working Voltage:
|
DC 8V-50V
|
|
Operating temperature:
|
-40℃~75℃
|
|
Storage temperature:
|
-45℃~85℃
|
|
Humidity:
|
0-95% RH non condensing
|
|
Lighting:
|
Red, Green light
|
|
Sound prompt:
|
Buzzer, single channel speaker (voice report)
|
|
Voice report prompt:
|
16KHz,16bit single channel voice report prompt
|
|
RFID:
|
Can read and write ISO14443 TYPE A\B Electronic tag (Incl. Combi-Card )
|
|
Read card distance:
|
0~50mm
|
|
Supporting card:
|
Mifare 1 card, Mifare DESfiire card,CPU card, UnionPay IC card
|
|
Frequency:
|
13.56MHz
|
|
Interfaces/Connectors:
|
RS232, RS485, USB
|
|
Printer modules:
|
Can be connected to slip printer-POS58
|
|
Width of receipt:
|
Based on printer configuration
|
|
Positioning mode:
|
GPS
|
|
Power consumption:
|
≤10W
|
|
Communication Modules:
|
4G
|
|
WIFI：
|
Supporting 802.11n/b/g standards,150Mbps,2.4Ghz
|
|
UnionPay:
|
Compatible for PBOC3.0 UnionPay card
|
|
Upgrading:
|
Connect USB to PC, upgrade with GPRS
|
|
Data collection:
|
WIFI, GPRS,3G,4G, USB
|
Engineered for Heavy-Duty Use
The Cardlan Linux Reader Commuter Bus RFID card reader is meticulously engineered to withstand the rigors of daily public transportation operations. Constructed with robust industrial-grade materials, this device is not only durable but also sealed to be dustproof, waterproof, and shockproof. It is resistant to electromagnetic interference, ensuring uninterrupted performance in any environment. This universal smart card reader is optimized for seamless integration into various BUS SOLUTION systems, making it an ideal choice for public transport, amusement parks, and employee shuttle services. With a dedicated stable power supply and voltage overload protection, the Cardlan Linux Reader guarantees reliability and longevity, reducing maintenance costs and downtime.
Seamless System Integration
Designed for versatility, the Cardlan Linux Reader supports a wide range of functionalities that cater to modern transportation needs. It is a contactless smart card reader that supports RFID cards, GPS positioning, and QR code scanning. The device is equipped with 4G and WiFi wireless communication capabilities, allowing for real-time data uploading and remote management. This wireless smart card reader can connect to server management software for time-revision, blacklist downloading, and data collection, ensuring efficient and secure operations. The IC/ID card reader functionality supports various card types, including Mifare and UnionPay IC cards, making it a comprehensive solution for electronic payments and card validation across multiple sectors.
Built for Modern Industry
The Cardlan Linux Reader is not just a mobile smart card reader; it is a complete BUS SOLUTION designed to enhance operational efficiency and user experience. With a 3.5-inch LCD display and a user-friendly interface, it provides live voice prompts in 15 different languages, catering to diverse user groups. The device supports consumption details and statistics queries, allowing operators to access detailed transaction data by card number, time, and operator number. Its advanced data capacity can store up to 91,880,000 card entries, ensuring scalability for growing operations. The rfid card reader is compatible with ISO14443 Type A/B electronic tags, offering a read card distance of up to 50mm, which enhances user convenience and speeds up transaction times. With its comprehensive features and robust design, the Cardlan Linux Reader is the ultimate choice for any organization looking to implement a reliable and efficient BUS SOLUTION.
Product Advantages
1.Robust and Durable Design
The Cardlan Linux Reader is engineered with industrial-grade materials, ensuring it withstands the rigors of daily use in public transportation environments. This universal smart card reader is not only dustproof and waterproof but also shockproof and resistant to electromagnetic interference, making it a reliable choice for any BUS SOLUTION. Its robust construction guarantees longevity and reduces maintenance costs, providing a high return on investment for businesses.
2.Advanced Connectivity Options
Equipped with cutting-edge technology, this wireless smart card reader supports 4G, WiFi, and GPS modules, allowing seamless integration into existing systems. The contactless smart card reader enables real-time data uploading and remote management, enhancing operational efficiency. This connectivity ensures that the rfid card reader can handle high volumes of transactions swiftly and securely, making it an ideal choice for modern public transport systems.
3.Comprehensive Card Compatibility
The Cardlan Linux Reader supports a wide range of card types, including Mifare, DESfire, CPU, and UnionPay IC cards, making it a versatile IC/ID card reader. This flexibility allows businesses to cater to diverse customer needs, ensuring a smooth and efficient payment process. As a mobile smart card reader, it adapts to various environments, from public buses to amusement parks, providing a comprehensive BUS SOLUTION.
4.User-Friendly Interface and Features
Featuring a 3.5-inch LCD display and live voice prompts, this smart card reader offers an intuitive user experience. The device supports up to 15 different voice prompts, such as "student card" or "employee card," making it easy for users to navigate. The contactless smart card reader also provides detailed consumption statistics and query options, allowing operators to manage and analyze data effectively.
5.Efficient Power Management
Designed with a dedicated stable power supply and voltage overload protection, the Cardlan Linux Reader ensures uninterrupted operation. This wireless smart card reader consumes less than 10W of power, making it an energy-efficient choice for businesses looking to reduce operational costs. Its efficient power management system supports the device's role as a reliable component in any BUS SOLUTION, ensuring consistent performance in various conditions.
