Name：
|
Smart Terminal
|
Data Capacity:
|
more than 2 million detailed data for console storage, extensible
|
|
Operating System：
|
Android7.1
|
Blacklist：
|
One hundred thousand pcs default，extensible
|
|
CPU：
|
Qualcomm eight-core 64-bit ARM Cortex-A53, built-in Qualcomm AdrenoTM 506 CPU, main frequency 2GHz
|
Working Temperature:
|
-20℃~65℃
|
|
RAM：
|
DDR3 2G
|
Storage Temperature:
|
-40℃~85℃
|
|
Data storage：
|
eMMC 16G（default）、Max support TF card expend to 64G
|
Working Humidity:
|
0-90%（non-condensing）
|
|
Dimension：
|
270x169x72mm(do not include installation parts)
|
Display：
|
8 inch TFT-LCD, 1280*800
LCD brightness can be 250cd/400cd optional, the default is 250cd, if the user has an outdoor use scene, it is recommended to
choose 400cd.
|
|
Housing material:
|
Engineering plastics
|
Indicator light：
|
Red and green
|
|
Scanning：
|
Wide angel/QR /customized
|
Sound Prompt：
|
Buzzer、Single channel loudspeaker
|
|
Facial recognition
|
Binocular, wide dynamic face recognition camera, default feature library capacity: 20,000
1. Binocular camera, support live detection;
2. Supports adaptation to different face algorithms;
3. Customers can choose the whole package or our company provides SDK secondary development kits or algorithms to assist customers
in application development.
|
Voice Prompt：
|
16KHz,16bit single channel voice prompt
|
|
Working Voltage：
|
DC 8V-55V
|
Support standard：
|
ISO-14443 Type A/B
|
|
Support Type
|
Support 1D code and 2D code
|
Reading Distance：
|
0~40mm
|
|
Communication Interface：
|
USB（type A）、USB（Micro 5pin）、RS485 and TTL-232 optional
|
Working Frequency：
|
13.56Mhz
|
|
Multi-screen display interface
|
HDMI(optional)
|
Card Type：
|
MiFare Classic, CPU card
|
|
Position way：
|
GPS、beidou （optional）
|
Working Mode：
|
Stand-alone or connect to server
|
|
Power Consumption:
|
≤15 W
|
Warning Function
|
Warning when card balance is insufficient or data memory is full
|
|
Communication mode
|
2G、3G、4G and USB collection,(WIF and bluetooth optional)
|
Relay
|
Relay output for turnstile/gate control (Optional)
|
Main features:Face recognition, 4G, Ethernet, WIFI, Bluetooth, GPS/Beidou, QR scanning, card reading
|
Reliable Fare Collection System
The CARDLAN bus validator is engineered for high-performance fare collection in public transport systems. With 4G connectivity and advanced RFID technology, it ensures fast and accurate ticket validation. Designed for buses and other public transit vehicles, it enables operators to enhance their service efficiency by ensuring smooth passenger flow. The bus ticket validator supports a wide range of contactless payment methods, reducing boarding times and improving overall operational efficiency. This system also integrates seamlessly with existing transit infrastructure, making it an ideal choice for modernizing ticketing systems in cities worldwide. Furthermore, its robust construction guarantees long-lasting durability, even under harsh conditions.
Smart Integration for Easy Management
One of the standout features of the CARDLAN bus card reader is its ability to integrate with existing transport management systems. This feature provides transportation authorities with real-time data on passenger flow and fare revenue, helping to optimize route planning and improve service delivery. The ticket validator uses advanced algorithms to ensure smooth and accurate validation, whether passengers use cards, smartphones, or other contactless devices. Additionally, its intuitive Android-based interface makes it easy for operators to configure and monitor the device. The bus reader is also equipped with GPS, allowing for location-based monitoring and ensuring that data collection is both accurate and relevant for reporting purposes.
Enhanced User Experience and Security
The CARDLAN bus ticket validator provides not only speed and efficiency but also enhanced security features. Its encrypted communication ensures that transaction data is securely transmitted, minimizing the risk of fraud. The easy-to-use interface enables passengers to quickly validate their tickets, while the system ensures high-speed data processing for uninterrupted service. As a result, both passengers and operators benefit from a secure, reliable, and user-friendly experience. The system’s ability to handle multiple ticketing formats (e.g., RFID cards, QR codes) also ensures that passengers have a variety of options for fare payment.
Product Advantages
Advanced RFID Technology
The CARDLAN Bus Validator is optimized for speed, ensuring that passengers can quickly tap their bus cards for validation. This reduces delays and improves the overall efficiency of bus services. The system employs cutting-edge RFID technology, offering high accuracy in ticket validation. By eliminating the need for manual checks, the validator streamlines the process and enhances operational efficiency for transport authorities.
User-Friendly Interface
Designed with both operators and passengers in mind, the bus ticket validator features a user-friendly interface. The screen is clear and intuitive, providing easy-to-read information for both bus drivers and passengers. Passengers can quickly understand the validation process, while operators have access to all necessary data for system monitoring and management. This simplicity ensures a smooth experience for all users.
Cost-Effective and Durable
Built to last, the CARDLAN Bus Validator offers long-term value for public transportation systems. Its durable design reduces maintenance costs, while its low power consumption makes it an energy-efficient choice for bus operators. The device's ability to withstand varying environmental conditions means it can function optimally across different climates, ensuring a reliable and cost-effective solution for fare validation.
About Us
Founded with a commitment to innovation, CARDLAN specializes in developing smart ticketing solutions for public transportation systems. With years of industry experience, we focus on providing advanced, reliable, and cost-effective fare collection systems. Our core products, including the bus validator and RFID bus card reader, are designed to meet the evolving needs of public transport operators worldwide. We prioritize quality, investing heavily in research, development, and testing to ensure the highest performance and reliability. As a trusted partner in the transit sector, CARDLAN is committed to delivering solutions that enhance operational efficiency, reduce costs, and improve the passenger experience.
FAQ
What types of cards can the CARDLAN Bus Validator read?
The CARDLAN Bus Validator supports a wide range of RFID cards, ensuring compatibility with most contactless bus cards, mobile tickets, and digital solutions.
How does the CARDLAN Bus Validator improve fare collection efficiency?
By utilizing advanced RFID technology, the bus ticket validator provides fast and accurate ticket validation, reducing wait times and improving overall system efficiency.
Can the CARDLAN Bus Validator be integrated with existing ticketing systems?
Yes, the bus card reader is designed to integrate seamlessly with existing ticketing systems, including Android-based POS machines, for a smooth transition and enhanced operational flexibility.
Is the CARDLAN Bus Validator suitable for outdoor use?
Yes, the CARDLAN Bus Validator is built to withstand harsh outdoor environments, with a weather-resistant design that ensures reliable performance in all conditions.
Does the CARDLAN Bus Validator support mobile ticketing?
Yes, the bus ticket validator can be integrated with mobile ticketing platforms, allowing passengers to use their smartphones for fare validation.
Upgrade your bus fare collection today with CARDLAN – efficient, reliable, and ready to enhance your transport system!
