Product Details：
Ø Product size: 1400*180*1020mm
Ø Material: 304# stainless steel
Ø Channel width: 600-800mm optional
Ø Power input: AC220V, 50Hz
Ø Drive mode: DC24V brushless DC motor
Ø Traffic direction: Support one-way and two-way
Ø Opening time: <1 second
Ø Product size: 1400*180*1020mm
Ø Material: 304# stainless steel
Ø Channel width: 600-800mm optional
Ø Power input: AC220V, 50Hz
Ø Drive mode: DC24V brushless DC motor
Ø Traffic direction: Support one-way and two-way
Ø Opening time: <1 second
Product advantages:
ØA new generation of industrial ARM control system, adding multi-functional digital setting, encryption and reset functions to facilitate user maintenance and use.
Ø Light indicator, fire input, alarm prompt function, adjustable speed, anti-reverse function,
Ø304 Brushed stainless steel, laser cutting process, internal welding, less external welding area, beautiful appearance
Ø The interior is clean and tidy, the line is organized, and it is easier to manage the space
Ø The use of 304 stainless steel raw materials, to achieve first-class quality, through professional technology, to develop powerful functions to meet the public consumption
Functional features:
Ø With fault self-test and alarm prompt function, easy to maintain and use
Ø Can be connected to any control device output control signal or button or remote control, to achieve single and dual control passage.
Ø Automatic reset function: every 90 degrees of swing, and detect people and objects through, that is, automatic reset, or in the specified time (delay multi-file adjustable) did not pass, the system will automatically cancel the permission to pass and return to the initial bit
Ø Light indicator: high brightness traffic light status indicator, guide traffic.
ØFire input: can be connected with the fire alarm signal to achieve constant power drop rod normally open.
Ø Alarm prompt function: When illegal passage or sluice, automatic alarm prompt is issued.
ØAdjustable speed: The opening and closing speed of the swing arm can be adjusted in multiple stages, and users can set it according to actual needs.
ØA new generation of industrial ARM control system, adding multi-function digital setting, encryption and reset functions.
Ø Anti-reverse function: in the process of swing arm reset, if the external force reverses the swing arm, the swing arm automatically starts the reverse thrust and sends an alarm, and automatically returns to zero position to resume traffic after the external force disappears.
ØAutomatic protection function: When the external force prevents the normal movement of the swing arm, and the external force is continuous, the system will automatically detect the automatic protection and enter the sleep state after 20 seconds. When the next legitimate signal input, the gate will automatically return to normal.
Ø Multi-stage anti-collision buffer function: when illegal passage or sluice, the brake rod buffers the corresponding Angle and starts the instant reverse thrust, while starting the alarm, which greatly reduces the mechanical damage caused by frequent or continuous collision while realizing the humanized damage prevention.
ØUnmanned duty: power off swing arm automatically open, power automatically reset (blocking passage).
